A14 Series Gasket Plate Heat Exchanger Ti,ti-pd Material For Chemical HVAC Electronic Industry
Introduction :
Gasket Plate Heat Exchanger is a heat transfer device that consists of a series of individual plates that can be easily disassembled and reassembled. Each plate has special patterns that create flow channels for the hot and cold fluids, allowing efficient heat exchange to occur. The detachable design offers flexibility for maintenance, cleaning, and modifications.
Product Features:
| TYPE | A(mm) | B(mm) | C(mm | D(mm) | E(mm) | Height ( mm ) ( from middle of bottom to ground ) (mm) | MAX.LC (mm) | Connector Path ( mm ) (mm) | Max Flow ( m3/h ) (m3/h) | Design Pressure (Mpa) | Max Pieces |
| A8 | N(2.3+X) | 200 | 70 | 750 | 656 | 51.5 | 500 | 28 | 18 | 10/1.6 | 95 |
| AS7 | N(2.3+X) | 300 | 126 | 660 | 394 | 160 | 500 | 60 | 36 | 1.0/1.6 | 200 |
| A14 | N(2.3+X) | 300 | 126 | 960 | 694 | 160 | 1200 | 60 | 36 | 1.0/1.6 | 200 |
| A19 | N(2.3+X) | 382 | 192 | 995 | 701 | 165 | 1200 | 66 | 36 | 10/1.6 | 250 |
